Model: JWS150-A41
● Display size: 15 inch
● LED panel support 1024 x 768 pixels
● Pre-installed Android OS
● Offer SDK for further development
● True flat front panel, elegant appearance
● Front 10mm aluminum bezel with IP65-grade protection
● Capacitive touch screen, precise positioning, free control
● Easy-to-install, support desktop stand / wall-hanging / VESA75/100mm
● Support customization service for functional modules, color, I/O interfaces, etc
15 Inch Android Industrial Touch Screen Computer
Model: JWS150-A41
Jawest reliable rugged tablets are commonly deployed in manufacturing, construction, warehousing, distribution, transportation, freight, self-service terminals, and other indoor and outdoor environments. It is a 15-inch display with the Android operating system and also supports Windows or Linux. With enriched experience in the industrial computer industry, we are engaged in offering high-grade industrial panel PC with Windows or Android OS. The offered panel PC is precisely designed under the direction of our professionals using advanced technology keeping in mind all standards of the industry. The panel PC is tested on a variety of parameters to eradicate all faults. Our panel PC is available in varied customized options in order to meet the specific demands of customers.
Key Features
a. Multi-Touch Panel
The highlight of this industrial computer is its multi-touch capacitive screen. The multi-touch functionality enables operators to perform various gestures such as pinch-to-zoom, swiping, and tapping, enhancing the overall user experience. This capability allows for smoother, more intuitive control over complex operations, which is particularly useful in industries requiring precision.
b. Durable and Robust Design
The device is engineered to withstand challenging environments. Its IP-rated enclosure protects the unit against dust, water, and harsh chemicals commonly found in industrial settings. The high-quality aluminum or stainless-steel housing ensures the system is resistant to physical shocks, vibrations, and extreme temperatures, making it a reliable option in factories, warehouses, and other demanding environments.
c. High-Definition Display
With a 15-inch display, this touchscreen computer offers a clear and sharp viewing experience, ensuring that operators can easily monitor systems, read data, or control processes. The resolution typically ranges from HD to Full HD, offering vibrant colors and clear visual feedback even in low-light or outdoor environments.
d. Android Operating System
The choice of the Android OS is a game-changer for industrial computing. Android provides a familiar interface to most users, reducing the learning curve. It also offers a wide range of compatible applications that can be easily downloaded from the Google Play Store, which is a significant advantage over traditional, proprietary industrial software. Additionally, Android’s open-source nature allows for greater customization according to specific industry needs.
e. Connectivity Options
Modern industrial touchscreen computers are equipped with a wide range of connectivity options, including Wi-Fi, Bluetooth, USB, HDMI, Ethernet, and even 4G/5G support for seamless communication between devices. These options enable real-time data collection, transfer, and cloud-based analytics—essential features for implementing Industry 4.0 and IoT technologies in industrial settings.
f. Efficient Processing and Memory
The 15-inch Android Industrial Computer comes with powerful ARM-based processors that ensure fast and efficient operation. With ample RAM (ranging from 2GB to 8GB or more) and storage (32GB to 256GB SSD options), the device can handle multiple industrial applications simultaneously. Some models even support expansion slots for additional storage, catering to more data-intensive operations.
Display Parameters | Size | 15" | |||||
Resolution | 1024*768 | ||||||
Screen Ratio | 4:3 | ||||||
Brightness | 350 nits (Optional high brightness) | ||||||
Contrast Ratio | 1000:1 | ||||||
Viewing Angle | 89°/89°/89°/89° (L/R/U/D) | ||||||
Backlight type | LED backlight screen, service life ≥ 50000H | ||||||
Touch Screen | Capacitive (Resistive, or Non-touch options) | ||||||
Motherboard Model Selection | JWS64 | JWS3288-I | JWS3399-MAIN-L | CX3399-A | CX3568-A | CX3588-A | |
System Architecture | CPU | A64 Quad-Core 1.5GHz | RK3288 Quad-Core 1.8GHz | RK3399 Six-Core 2.0GHz | RK3399 Six-Core 2.0GHz | RK3568 Quad-Core 2.0GHz | RK3588 Octa-Core 2.1GHz |
Core Architecture | Cortex-A53 | Cortex-A17 | Dual-Core Cortex-A72 + Quad-Core Cortex-A53 | Dual-Core Cortex-A72 + Quad-Core Cortex-A53 | Cortex-A55 | Quad-Core Cortex-A76 + Quad-Core Cortex-A55 | |
GPU | Mali-T764 | Mali-T764 | Mali-T860 MP4 | Mali-T860 MP4 | Mali-G52 2EE | Mali G610 MP4 | |
Memory (DDR) | 2GB (8GB optional) | 2GB (4GB optional) | 4GB | 2/4GB | 2GB (4/8GB optional) | 4GB (8/32GB optional) | |
Storage (eMMC) | 16GB (32/64GB optional) | 16GB (32/64/128/256GB optional) | 32GB (64GB optional) | 32/64GB (256GB optional) | 32GB (64/128/256GB optional) | 64GB (128/256GB optional) | |
SATA | / | / | / | / | Support | / | |
Operating System | Android 6.0 | Android 7.1 / 10.0 | Android 7.1 / 9.0 / 11 | Android 7.1 / 9.0 / 11 | Android 12/14 | Android 13.0 | |
/ | Linux 4.4 | Linux 4.4 | Linux 4.4 | Linux 5.10 | Linux 5.10 | ||
/ | Ubuntu 18.04 | Ubuntu 18.04 | Ubuntu 18.04 | Ubuntu 20.04 | Ubuntu 20.04 | ||
/ | Debian 10.0 | Debian 10.0 | Debian 10.0 | Debian 11.0 | Debian 11.0 | ||
Networking | Ethernet | 1*10M/100M/1000M adaptive Ethernet | 1*Gigabit Ethernet + 1*100 Mbit Ethernet | ||||
4G | Optional. Based on the 4G module selection | ||||||
5G | / | / | / | / | / | / | |
WIFI | 2.4G | Dual-band 2.4/5G | Dual-band 2.4/5G | Dual-band 2.4/5G | WIFI6, 2.4G | WIFI6, Dual-band 2.4/5G | |
Bluetooth | BT5.0 | BT5.0 | BT5.0 | BT5.0 | BT5.2 | BT5.0 | |
Touch Function | Touch Interface | USB/IIC | USB | USB/IIC | |||
I/O Ports | USB | 1*USB HOST, 1*USB OTG | 1*USB HOST, 1*USB OTG | 1*USB HOST, 1*USB OTG | 1*USB, 1*OTG | 2*USB3.0 | 1*USB, 1*OTG |
HDMI | 1*HDMI, up to 4K | 1*HDMI, up to 4K | 1*HDMI, up to 4K | 1*HDMI, up to 4K | 1*HDMI, up to 4K | 1*HDMI, up to 4K | |
LAN | 1*LAN | 1*LAN | 1*LAN | 1*LAN | 1*LAN | 2*LAN | |
DC | 1*DC2.1 | 1*DC2.1 | 1*DC2.1 | 1*DC2.1 | 1*DC2.1 | 1*DC2.1 | |
COM | 2*RS232+2*Reserved holes | 1*RS232+1*Reserved hole | |||||
TF/SIM | 1* TF/SIM slot | 1*TF/SIM slot | 1*TF/SIM slot | 1*TF/SIM slot | 1*TF/SIM slot | 1*TF/SIM slot | |
WiFi Antenna | 1*WiFi Antenna | 1*WiFi Antenna | 1*WiFi Antenna+1*Reserved hole | ||||
Audio I/O | 1*3.5mm Earphone Jack | ||||||
Reset Button | 1*UBOOT | 1*UBOOT | 1*UBOOT | 1*UBOOT | 1*UBOOT | 1*UBOOT | |
GND | 1*GND | 1*GND | 1*GND | 1*GND | 1*GND | 1*GND | |
MICRO OTG | 1*MICRO OTG | / | / | / | / | / | |
1*12P Phoenix Terminal | / | / | / | 1*DC | 1*DC | 1*DC | |
/ | / | / | 1*RS232 | 1*RS232 | 1*RS232 | ||
/ | / | / | 1*RS485 | 1*RS485 | 1*RS485 | ||
/ | / | / | 1*TTL | 1*CAN | 1*CAN | ||
/ | / | / | 3*GPIO | 3*GPIO | 3*GPIO | ||
I/O Expansion | Support | ||||||
Power | Power Input | 12V DC | 12V DC | 12-36V DC | 12-36V DC | 12-36V DC | 12-36V DC |
Adapter | 12V / 4A | 12V / 4A | 24V / 2.5A | 24V / 2.5A | 24V / 2.5A | 24V / 2.5A | |
Mechanical | Enclosure | Aluminum alloy housing | |||||
Cooling System | Fanless | ||||||
Mounting | Desk stand, wall-hanging, VESA75/100mm, etc. | ||||||
Product Reliability | Working Temp | -10°C ~ 60°C | |||||
Storage Temp | -20°C ~ 70°C | ||||||
Ambient Humidity | 5% - 95% (relative humidity non-condensing) | ||||||
IP rating | Front IP65 |
